XBS-9-P(D4-8)
Type：Cable Connector-XBS(Plastic waterproof joint)
Model：XBS-9-P(D4-8)
Num：3209090160
Part：Cable Connector
Introduction：PG9 ordinary plastic cable waterproof connector; black
Download：
XBS-9-P(D4-8)
Detail
| Ordinary plastic waterproof cable connector | |
| Material | Nylon |
| Seals | Ding Qing rubber |
| Protection level | IP68 (in case of O-ring) |
|
Temperature range |
Static ：-40℃-100℃ Dynamic ：-20℃-80℃ |
| Tread size | PG9 |
| Bayonet range | 4-8mm |
| Thread outer diameter | 15.2mm |
| Wrench size | 19mm |
| Thread length | 8.0mm |
