XBS-16-P(D8-14)
Type：Cable Connector-XBS(Plastic waterproof joint)
Model：XBS-16-P(D8-14)
Num：3209160160
Part：Cable Connector
Introduction：PG16 ordinary plastic cable waterproof connector; black
Download：
XBS-16-P(D8-14)
Detail
| Ordinary plastic waterproof cable connector | |
| Material | Nylon |
| Seals | Ding Qing rubber |
| Protection level | IP68 (in case of O-ring) |
|
Temperature range |
Static ：-40℃-100℃ Dynamic ：-20℃-80℃ |
| Tread size | PG16 |
| Bayonet range | 8-14mm |
| Thread outer diameter | 22.5mm |
| Wrench size | 27mm |
| Thread length | 10mm |
